Proprietary Emulsion - Technical Data Sheet

gelpac mg-2500               Spec

 Density .......................................................1.21 (G/CC)

Velocity of Detonation..............................20,300 (FT/SEC)

                                                    ......................6,187.4 (M/SEC)

                                                    ......................4.5 - INCH BORE

Absolute Weight Strength.......................0.88

Calculated Using Under Water Pressure Pulse Bubble Test
With ANFO = 1.00 @ 0.82 (G/CC)

Absolute Bulk  Strength......................1.06

Relative Bulk Strength.........................1.29

Detonation Pressure............................116.18 (Kbars)

Minimum Diameter...............................1.5-Inch (38.1mm)

Minimum Primer Size............................ 0.75-Pounds

Sleep Time..................................................2-months

All values above based on actual performance test results and NOT calculated by using computer models.

HAZARDOUS SHIPPING DESCRIPTION: UNITED STATES

Explosives, Blasting, Type E, Gel Pac R.P.

EX2009120415 - DOT-SP4453 or

DOT-SP8815

UNO332
